Forklift Throttle Body
Forklift Throttle Body - Where fuel injected engines are concerned, the throttle body is the part of the air intake system which regulates the amount of air which flows into the engine. This particular mechanism works in response to operator accelerator pedal input in the main. Normally, the throttle body is positioned between the air filter box and the intake manifold. It is usually fixed to or situated near the mass airflow sensor. The largest component within the throttle body is a butterfly valve referred to as the throttle plate. The throttle plate's main function is to be able to control air flow.
On various styles of vehicles, the accelerator pedal motion is communicated through the throttle cable. This activates the throttle linkages which in turn move the throttle plate. In automobiles consisting of electronic throttle control, otherwise known as "drive-by-wire" an electric motor controls the throttle linkages. The accelerator pedal connects to a sensor and not to the throttle body. This sensor sends the pedal position to the ECU or likewise known as Engine Control Unit. The ECU is responsible for determining the throttle opening based upon accelerator pedal position along with inputs from different engine sensors. The throttle body consists of a throttle position sensor. The throttle cable connects to the black part on the left hand side which is curved in design. The copper coil situated near this is what returns the throttle body to its idle position after the pedal is released.
Throttle plates revolve inside the throttle body each and every time pressure is applied on the accelerator. The throttle passage is then opened to allow more air to flow into the intake manifold. Normally, an airflow sensor measures this adjustment and communicates with the ECU. In response, the Engine Control Unit then increases the amount of fluid being sent to the fuel injectors in order to produce the desired air-fuel ratio. Frequently a throttle position sensor or also called TPS is connected to the shaft of the throttle plate to provide the ECU with information on whether the throttle is in the wide-open throttle or otherwise called "WOT" position, the idle position or somewhere in between these two extremes.
In order to control the minimum air flow while idling, some throttle bodies may have valves and adjustments. Even in units that are not "drive-by-wire" there will usually be a small electric motor driven valve, the Idle Air Control Valve or IACV that the ECU utilizes to regulate the amount of air which can bypass the main throttle opening.
It is common that several vehicles contain one throttle body, though, more than one can be utilized and attached together by linkages in order to improve throttle response. High performance vehicles like for instance the BMW M1, together with high performance motorcycles like for instance the Suzuki Hayabusa have a separate throttle body for every cylinder. These models are called ITBs or "individual throttle bodies."
The carburator and the throttle body in a non-injected engine are quite similar. The carburator combines the functionality of both the fuel injectors and the throttle body into one. They can modulate the amount of air flow and mix the fuel and air together. Vehicles which have throttle body injection, which is referred to as TBI by GM and CFI by Ford, situate the fuel injectors inside the throttle body. This allows an older engine the possibility to be transformed from carburetor to fuel injection without considerably changing the engine design.
